This corner mounting led neonflex with cross section W22mm*H10mm, max 10W/M 836LM/M, 83.6LM/W, consist of high bright SMD2216, dot-free and homogeneous emitting, IP67 rating by integrated silicone extrusion, integral silicone endcap and front entry only. DC24V and max run length is 5M from one end and without noticeable voltage drop, standard reel length is 5M and customized length is optional.
| Model No. | FE-HXX240F-E |
|---|---|
| SMD Type | Epistar SMD2216 |
| Led Qty(pcs/M) | 240LED/M |
| PCB Width | 6mm |
| Input voltage | DC24V |
| Current/M | 0.41A/M |
| Power/M | 10W/M |
| Lumen/M | 836LM/M |
| Efficiency(LM/W) | 83.6LM/W |
| CCT | 1800-6500K |
| CRI(Ra) | 90Ra |
| Cross Section(W*H) | 22x10mm |
| IP Rating | IP67 |
| Beam Angle | 120° |
| Cutting Unit | 24V:25mm |
| Length | 5M/Roll |
| Max Run | 5M from one side |
| Standard Packing | 5M/Roll |
| Warranty | 3 years |
| Working hour | 35000hours |
| Working temperture | -25°C~+45°C |
