Mini Cutting 8.33mm Top Bending Round 16mm IP67 Silicone LED Neon Flex

Hanky Top Bending 16mm Round IP67 Led Neonflex Size Diagram
Hanky Top Bending 16mm Round IP67 Led Neonflex cutting window
Hanky Top Bending 16mm Round IP67 Led Neonflex installation
Category Tags , , , , , , ,

The round diameter:16mm top bending led neonflex with top bending or vertical bending, mini cutting length 8.33mm, with Epistar SMD2835 120LED/M, ONE led a cut, min bending diameter 200mm, front cable entry, 670lm/M 10W/M 67LM/W, constant voltage design 24V, max run length 5M from one end without noticeable voltage drop. Standard length in 5M and customized length is optional, CCT 2700K/3000K/4000K/6000K is available.

Additional information

Model No.

FN-GXX120F-I-MINI
SMD Type

Epistar SMD2835 0.2W/LED
Led Qty(pcs/M)

120LED/M
PCB Width

8mm
Input voltage

DC24V
Current/M

0.41A/M
Power/M

10W/M
Lumen/M

670LM/M
Efficiency(LM/W)

67LM/W(10W@4000K)
CCT

2700K/3000K/4000K/6500K
CRI(Ra)

90Ra
Cross Section(W*H)

Diameter:16mm
IP Rating

IP67 Silicone Extrusion
Beam Angle

270°
Cutting Unit

24V:8.33mm
Length

5M/Roll
Max Run

5M from one side
Standard Packing

5M/Roll
Warranty

3 years
Working hour

50000h
Working temperture

-20°C~+45°C
ASK FOR A QUOTE

Products Details

  • Special design as round shape and beam angle up to 270degree, adopt to the DIY project.
  • Mini cutting 8.33mm by Epistar SMD2835 one led a cutting, 670lm/M 10W/M 67LM/W.
  • Dow Chemical SILASTIC™ ET-7021 silicone rubber, acids & alkali and UV resistance.
  • IP67 rating by integrated silicone extrusion molding process,indoors&outdoors application.
  • Top bending or vertical bending, emitting from top with dot-free and homogeneous luminance.
  • 3-step macadam and one bin leds, to ensure the color consistency was the same in the different batches.
  • Silicone endcap, front cable entry.
  • Diameter 16mm, top view and vertical bending with min bending radius 200mm, can be the shape you want.
  • Unique optical light distribution structure design, uniform lighting surface and no shadow.
  • Constant voltage 24V design, and max run length 5M from one end without noticeable voltage drop.
  • Standard length in 5M and customize length is optional.
